ENGINEERED
RETAINING
WALLS®

Leaning, bulging, stair-step cracking, separated caps, sinking sections, leaking water, and soil washing out are the biggest red flags.

It can be. Movement means the wall is losing resistance. If the wall is near a driveway, home, pool, or slope edge, it should be evaluated quickly.

Sometimes. If movement is minor and the base is stable, repairs like drainage correction, reinforcement, or geo-anchors may work. Severe lean or base failure usually requires rebuild.

Bad drainage, poor backfill, weak base prep, no reinforcement, and building on loose fill are the top causes. Water pressure is the #1 killer.

We remove failed material, rebuild on competent footing, install engineered drainage and clean stone, and use geogrid or earth anchors when required.

Small repairs can take a few days. Full rebuilds typically run 1–3 weeks depending on height, access, and drainage/engineering needs.

For tall walls, steep lots, or walls supporting structures, yes. Engineering sets reinforcement, drainage, and safety requirements.

Yes. When excavation, reinforcement, compaction, and drainage are done to code, engineered walls are built for decades of performance.

Yes. ERWalls provides workmanship warranties, and engineered systems are backed by design standards and inspection documentation.

Yes. We specialize in steep and hard-access sites and can mobilize by barge or crane when needed.

Big-block retaining wall systems use large precast concrete units — typically 1,500 to 5,000+ lbs per block — set into place with excavating equipment or a crane rather than by hand. The mass and interlocking geometry of these blocks creates a gravity-resistant wall capable of retaining much taller sections than standard hand-placed segmental block. They're widely used for commercial applications, tall residential walls, and any site where height, speed of installation, or structural performance demands exceed smaller block systems.

We install engineered big-block systems including Redi-Rock, MagnumStone, and other site-appropriate large precast products, as well as custom large-block configurations using plant-cast structural concrete blocks. Product selection depends on wall height, aesthetics, engineering requirements, and block availability for the project location. Our engineers evaluate which system best fits your site's structural demands, available space, and budget before specifying a product.

Big-block walls are the better choice when you need significant wall height in a compact footprint, when site access limits hand-placing of smaller units, when rapid installation speed is important, or when structural demands — heavy surcharge loads, steep terrain, proximity to structures — call for a high-mass system. They're also preferred when clients want specific precast textures or aesthetics, and on hard-access sites where fewer lifts per crane pick is a cost advantage.

Yes — for taller walls or steep lots, big-block faces are routinely paired with geogrid and clean crushed-stone backfill to form a reinforced earth (MSE) structure. In this configuration the block face acts as an erosion barrier and aesthetic finish, while the combined geogrid-and-stone mass behind it provides the structural resistance. This is the standard approach for big-block walls over 10–12 feet and one of the strongest retaining systems available for residential and commercial applications.

Properly engineered big-block walls can be built to very significant heights — walls over 30 feet are not uncommon, and with appropriate engineering, drainage, and geogrid reinforcement, heights well over 50 feet are achievable. The practical limit is determined by engineering, available space for geogrid embedment behind the wall, drainage design, and site access for the excavation required. Our engineers have designed and built some of the tallest residential retaining walls in the Southeast.

Absolutely — drainage is just as critical in a big-block wall as in any other retaining system. Every big-block installation we build includes a full clean-stone drainage zone behind the blocks, perforated collection pipe at the base, and positive drainage outlets to daylight at regular intervals. Omitting drainage from a big-block wall — regardless of how massive the blocks are — leads to hydrostatic pressure buildup and eventual failure. Block mass alone cannot substitute for proper drainage.

Big-block systems are well suited to hard-access properties because the blocks can be set by crane, delivered by barge, or staged and craned into tight positions that smaller equipment can't reach. Their weight-per-unit means fewer individual placements to complete a wall section, which reduces crane time on lake and mountain access projects. This efficiency makes big-block systems cost-competitive on constrained sites even accounting for crane mobilization.

Both are engineered precast concrete big-block systems designed for equipment-set retaining walls, but they differ in block geometry, interlocking connection methods, available face textures, and the specific height and loading applications each system is optimized for. Redi-Rock uses a round-nose interlocking design with various face textures. MagnumStone uses a different alignment and stacking system. We specify whichever system's engineering and geometry best fit the site height, reinforcement requirements, and aesthetics — and sometimes use both on the same property.

Most tall walls, walls within 10 feet of structures, and any wall on steep terrain require a licensed PE to design the reinforcement, base, drainage, and global stability. Big-block systems are not exempt from engineering requirements simply because the blocks are heavy — a tall unengineered big-block wall can still fail from inadequate drainage, base movement, or insufficient geogrid on loaded sites. We require engineering on any big-block installation meeting the code triggers for NC, GA, or TN.

Big-block retaining walls built with proper base excavation, engineered drainage, and reinforced backfill where required are designed for multi-decade service life. The precast concrete blocks themselves are extremely durable — they don't degrade, rot, or rust. Long-term performance depends almost entirely on drainage maintenance and whether the original installation met engineering requirements. Walls we built in this region over 15 years ago continue to perform without movement or maintenance issues.
